| M12 – M36 (NL12SC – NL36SC) |
| GF = ratio of yield point |
| μg |
| = thread friction |
| μw = washer friction |
| 1ft = 0,3048 m |
| 1lb = 0,4536kg = 4,450 N |
| 1ftlb = 0,3048 x 0,4536 x 9,81 = 1,356 Nm |
| NL3 #5 40 1.1 550 1.0 550 1.1 450 |
| NL3.5 #6 32 1.4 630 1.3 630 1.5 520 |
| NL4 #8 32 2.7 970 2.4 970 2.6 800 |
| NL5 #10 24 3.9 1,200 3.5 1,200 4.0 1,000 |
| NL1/4” 1/4 20 9.1 2,200 8.3 2,200 9.0 1,800 |
| NL8 5/16 18 18 3,600 16 3,600 18 3,000 |
| NL3/8” 3/8 16 30 5,400 28 5,400 31 4,400 |
| NL11 7/16 14 47 7,300 42 7,300 47 6,100 |
| NL1/2” 1/2 13 73 9,800 66 9,800 74 8,100 |
| NL14 9/16 12 104 12,600 94 12,600 104 10,400 |
| NL16 5/8 11 145 15,600 131 15,600 146 12,900 |
| NL3/4” 3/4 10 254 23,100 230 23,100 257 19,100 |
| NL22 7/8 9 408 31,900 369 31,900 413 26,400 |
| NL1” 1 8 617 41,800 557 41,800 624 34,600 |
| NL30 1 1/8 7 771 46,400 697 46,400 780 38,400 |
| NL33 1 1/4 7 1075 58,900 969 58,900 1090 48,700 |
| NL36 1 3/8 6 1410 70,200 1270 70,200 1430 58,100 |
| NL39 1 1/2 6 1860 85,500 1670 85,500 1880 70,600 |
| NL3 #5 40 1.5 740 1.3 780 |
| NL3.5 #6 32 1.9 840 1.7 890 |
| NL4 #8 32 3.5 1,300 3.1 1,400 |
| NL5 #10 24 5.1 1,600 4.6 1,700 |
| NL1/4” 1/4 20 12 2,900 11 3,100 |
| NL8 5/16 18 24 4,900 21 5,100 |
| NL3/8” 3/8 16 41 7,200 36 7,600 |
| NL11 7/16 14 64 9,800 56 10,400 |
| NL1/2” 1/2 13 99 13,100 86 13,900 |
| NL14 9/16 12 138 16,800 122 17,800 |
| NL16 5/8 11 197 20,900 171 22,100 |
| NL3/4” 3/4 10 346 30,900 299 32,700 |
| NL22 7/8 9 556 42,700 479 45,100 |
| NL1” 1 8 840 56,000 724 59,200 |
| NL30 1 1/8 7 1190 70,600 1030 74,500 |
| NL33 1 1/4 7 1660 89,600 1430 94,600 |
| NL36 1 3/8 6 2180 107,000 1880 113,000 |
| NL39 1 1/2 6 2870 130,000 2470 137,000 |
